Overview of NFPA 13 Section 26.6 and CMDA in Cartoned Records Storage

NFPA 13 Section 26.6 provides a framework for CMDA in environments where cartoned records are stored on elevated catwalks. The provision focuses on ensuring that modifications or deviations to standard sprinkler design still deliver effective coverage, maintain hydraulic reliability, and preserve safe access for personnel performing routine tasks or maintenance. In practice, facilities must align CMDA decisions with the specific geometry of cartoned storage, the location and accessibility of catwalks, and the potential impact on fire protection performance.

From a commercial facilities perspective, implementing CMDA within cartoned records storage demands disciplined coordination among design professionals, building owners, and the fire protection contractor. The emphasis is on verifiable design rationales, documented inspections, and traceable maintenance activities to prevent coverage gaps or access obstructions that could compromise safety, business continuity, and insurance compliance. The standard encourages ongoing collaboration to meet local code expectations while preserving operational efficiency.

CMDA for Cartoned Records Storage Design: Key Considerations

Storage geometry and sprinkler placement

CMDA reviews must account for the dense stacking of cartons, aisle widths, and the proximity of storage to sprinklers. Designers evaluate how modifications influence hydraulic demand, sprinkler head coverage, and the ability to intervene safely when records are accessed on the catwalk. A critical outcome is maintaining adequate spray reach and penetration without creating dead zones behind racks.

Hydraulic calculations and demand class

Engineering teams document corrected hydraulic calculations that reflect CMDA decisions. This includes assuring that supply water, pressure, and flow rates satisfy the modified layout, even when catwalk access introduces unique fire protection challenges. Clear, auditable records support compliance during inspections and audits.

Catwalk Access: Ensuring Safe Egress and Unobstructed Operation

Catwalk design and guardrail standards

Catwalks must be designed to support routine access to stored records while maintaining worker safety. Guardrails, midrails, and toe boards are specified to prevent falls and to keep paths clear during retrievals, routine checks, and sprinkler system testing. The layout should minimize obstruction to sprinkler heads and allows unobstructed ingress and egress to equipment and control valves.

Aisle clearance and headroom considerations

Aisles adjacent to catwalks require adequate clearance to accommodate movements of personnel and carts without compromising sprinkler spray patterns. CMDA considerations drive documentation of clearance calculations, ensuring that headroom remains sufficient even when pallets or cartons are moved into and out of the area.

Inspection, Testing and Maintenance for CMDA Activated Cartoned Storage

Routine inspection protocol

Inspection protocols focus on verifying access routes, catwalk integrity, and protection features around modified sprinkler layouts. Technicians document any obstructions, damaged guards, or compromised hangers that could affect sprinkler performance or worker safety.

Testing cadence and documentation

Testing includes functional checks of valves, alarms, and, where applicable, deluge or deluge-type systems adapted for CMDA configurations. Accurate test records demonstrate that the modified design continues to meet performance criteria while ensuring rapid notification in the event of a sprinkler discharge.

Practical Compliance Challenges in Commercial Facilities and the Kord Fire Protection Advantage

Common challenges you may encounter

• Obstructions on access routes due to cartoned storage movement or maintenance tasks
• Inconsistent maintenance scheduling that leads to degraded access or degraded protection features
• Unclear responsibility boundaries between owners, maintenance teams, and CMDA designers
• Difficulty reproducing hydraulic calculations after layout changes or equipment replacements

Best practices for staying compliant

• Establish a formal CMDA review process for any storage reconfiguration near catwalks
• Maintain up-to-date as-built drawings, including all CMDA rationales and approved deviations
• Schedule regular walkthroughs to verify access, clearance, and guardrail integrity
• Coordinate with a qualified fire protection partner to perform periodic testing and maintenance

Kord Fire Protection serves as a vital commercial service partner for ongoing CMDA compliance, testing, and maintenance. Their team offers design reviews, hydraulic recalculations, installation oversight, and routine inspections tailored to cartoned records storage with catwalk access. By leveraging Kord’s expertise, facilities maintain continuous readiness and reduce the risk of noncompliance in dynamic commercial environments.

Frequently Asked Questions

With NFPA 13 CMDA cartoned records storage catwalk access, proactive design, rigorous maintenance, and ongoing professional guidance are essential. Kord Fire Protection offers comprehensive CMDA services, including design review, hydraulic analysis, installation oversight, and sustained maintenance programs to keep facilities compliant and safe.

To ensure ongoing compliance and reliable protection for cartoned records on catwalks, contact Kord Fire Protection for a CMDA compliance review, on-site assessment, and a tailored maintenance plan that fits your facility’s schedule and budget.
